YETUO SW-CJ-2FD Clean Bench
Model: SW-CJ-2FD
Product Overview
The SW-CJ-2FD clean bench features vertical airflow and a working area measuring 1360×590×540 mm (W×D×H). Its double-person, single-sided design provides a shared workspace for two operators and is suitable for routine laboratory clean operations, research experiments, and related precision work.
When selecting a model, consider the number of operators, available workspace, and experimental workflow. Confirm the equipment configuration according to the intended application.
Related model: SW-CJ-1D Single-Person, Single-Sided Clean Bench.
The SW-CJ-2FD features vertical airflow and a two-person, single-sided operator arrangement. Its working area measures 1360×590×540 mm (W × D × H).
The work surface is made of stainless steel. Before selection, check the working space required by your equipment, the installation location and the intended workflow.
| Parameter | SW-CJ-2FD |
|---|---|
| Model | SW-CJ-2FD |
| Colony count | ≤0.5 colonies per dish per hour (Φ90 mm culture dish) |
| Average air velocity | 0.25–0.45 m/s (two-speed adjustment) |
| Noise level | ≤62 dB(A) |
| Vibration half-amplitude | ≤0.5 μm (X, Y and Z directions) |
| Illuminance | ≥300 lx |
| Power supply | Single-phase AC 220 V, 50 Hz |
| Weight | 160 kg |
| HEPA filter dimensions and quantity | 1355×555×38 mm; quantity: 1 |
| Fluorescent / UV lamp rating and quantity | Fluorescent: 30 W × 1; UV: 30 W × 1 |
| Operator arrangement | Two-person, single-sided |
| Working area (W × D × H), mm | 1360×590×540 |
| Overall dimensions (W × D × H), mm | 1540×680×1600 |
Working-area dimensions and overall dimensions describe different parts of the equipment. Confirm the installation space and required configuration before ordering.
Related model: YETUO SW-CJ-1D Clean Bench.
