YTLG-20F Silicone Oil Heating 0.2 Square Freeze Drying Machine Product Features

7-inch true color LCD touch screen, with important parameters (cold trap temperature/sample temperature/vacuum degree/partition temperature, etc.) intuitively visible.

The compressor and vacuum pump circuits are controlled by separate switches to prevent frequent start stop of the compressor caused by misoperation.

The freeze-drying data is automatically saved, viewed in real-time, and reproduced in history, making the freeze-drying process clear and controllable.

● It can store freeze-drying formulas, with 36 editable segments per group, which can be called up at any time, and can be customized for renaming, achieving direct recognition and differentiation.

● It has the function of automatically saving freeze-dried data when powered off, and can support exporting and viewing data from USB flash drives.

Adopting imported compressors, the refrigeration is fast, the refrigeration efficiency is higher, and the reliability is better.

Using fluorine free refrigerants can meet environmental requirements.

Preferred brand vacuum pump, corrosion-resistant, silent, and leak free.

Standard vacuum pump oil mist filter ensures laboratory environment and reduces oil mist pollution.

The drying chamber and cold trap dual chamber design provide more stable water capture and larger operating space.

The design of a large cold trap increases the surface area of the water capture device.

The observation door is made of colorless and transparent organic glass for easy observation.

All Chinese machines include regular and capping types. The movable plate layer supports capping and storage of penicillin bottles, while the fixed plate layer supports freeze-drying of ampoules, penicillin bottles, glass flasks, plasma bottles, or plates.

Reduce tedious operations, minimize material contamination risks, and ensure the safety of laboratory personnel and samples.

Yetuo YTLG-20F Silicone Oil Heating Type 0.2 Square Freeze Drying Machine Detailed Parameters

model

YTLG-20F

Specifications

Ordinary silicone oil heating

Freeze dried area

0.2㎡

Water catching capacity

6kg/batch

Plate packaged solution

3L

Board size (length mm)

four hundred

Board size (width mm)

two hundred and seventy

Board layer spacing

70mm

Number of layers

2+1 pieces

Temperature range of the board layer (unloaded)

-50°C~+70°C

Minimum temperature of cold trap

-80 ° C (unloaded)

Ultimate vacuum degree

≤ 10pa (empty load)

power

3..0Kw（220V）

ambient temperature

≤25°C

Dimensions (mm)

800x800x1480

Supporting vacuum pump

4L/S

Whole machine weight (kg) The specific weight is based on the actual weight

200kg
