Model: SX2-5-12N
Environmental temperature: 0-50 ° C
Temperature control range: room temperature -1200 ° C
Reachable temperature: ≤ 1000 ° C
Temperature control accuracy: ± 1 ℃
Temperature fluctuation: ± 1 ℃ (test point 600 ° C)
Temperature equilibrium: ± 3 ° (test point 600 ° C)
Heating rate: below 700 ° C, about 15 degrees per minute
Furnace size (mm): 300x200x120
External dimensions (mm): 610x470x640
Weight gross weight: ≈ 50kg
Volume: ≈ 7.2L
Input power: 5kw
Power supply voltage: 380V
Yetuo SX2-5-12N integrated box type resistance furnace
Model: SX2-5-12N
Product Overview:
This furnace is a universal equipment for laboratories, which can be used for sintering, heating, and treatment in coal, chemical, building materials, electricity, metallurgy, geological exploration, and research unit laboratories;
Features of Ye Tuo SX2-5-12N Integrated Box Resistance Furnace
Clever furnace door design makes the door opening operation completely simple, ensuring that high-temperature hot gas in the furnace does not leak out;
Installing the controller under the furnace door can save space and meet various requirements for rapid sintering;
The microcomputer PID controller is easy to operate, with accurate, reliable, and comprehensive temperature control;
● Corrosion resistant lightweight furnace, ensuring long-term use;
Good door sealing reduces heat loss and increases the uniformity of temperature inside the furnace;
