Product Parameters:
Product model: THZ-200B
Constant temperature method: forced convection
Oscillation mode: cyclotron oscillation
Performance:
Temperature range for use: 4~60 ° C (when the ambient temperature is 25 ° C)
Rotation frequency: 40-400rpm
Frequency accuracy: ± 1rpm
Swing amplitude: φ 26mm
Temperature control accuracy: ± 0.1 ° C (constant temperature state)
structure
Box material: corrosion-resistant 304 stainless steel
Shell material: High quality steel plate material
controller:
Temperature control method: P.I.D. microcomputer processing chip
Temperature setting method: Touch button setting
Temperature display mode: LCD liquid crystal display
Heating method: U-shaped heating tube
Additional functions: Deviation correction, menu button locking, power outage compensation, power outage memory, PID adjustable
Sensor: PT100
Safety devices: overtemperature alarm, short circuit protection, overheating protection, sound and light alarm
Specifications
Standard configuration: 50mlx4/100mlx4/250mlx3/500mlx3
Maximum capacity: 50ml x 20/100ml x 16/250ml x 12/500ml x 9
Tray size (mm): 450 × 370
Inner container size (mm): 440x405x270 (48L)
Dimensions (mm): 600x580x510
Packaging size (mm): 790x800x590
Power (W): 580W
Timing range: 0~9999min
Power supply: AC 220V ± 10% 50~60HZ
- Product Details
- Product manual
Yetuo THZ-200B desktop constant temperature shaker
Model: THZ-200B
Product Overview:
Desktop constant temperature shaker is a versatile biochemical instrument widely used in bacteria, fermentation, hybridization, biochemical reactions, and cell tissue research that require high temperature and oscillation frequency. It has a wide range of applications in fields such as medicine, biology, molecular biology, pharmaceuticals, food, and environmental protection.
Product features of Yetuo THZ-200B desktop constant temperature shaker
● Cultivate integrated oscillation
The combination of constant temperature cultivation and oscillation saves space, and the heating rate can be freely adjusted;
● Sturdy and Silent Luxury Window
ABS shell+mirror stainless steel inner cavity, tempered glass large window, silent design of the whole machine, beautiful and durable;
Intelligent memory power-off recovery
Tilted panel with large screen display, parameter memory, password lock, automatically resumes operation after power failure;
● Precise temperature control, rapid cooling and defrosting
When the temperature exceeds 3 ℃, it will stop heating and trigger an alarm, quickly cool down, and come with an automatic frost function;
Strong motor does not require maintenance
Long lasting and stable operation of high torque motors, maintenance free, reducing usage costs;
