Model: SW-CJ-2FD
Applicable number of people: double person, single side
Air flow direction: vertical flow
Cleanliness level: ISO 5
Colony count: ≤ 0.5 per dish (90mm culture plate)
Average wind speed: ≥ 0.3m/s
Noise: ≤ 62dB
Vibration amplitude: ≤ 4um
Illuminance: ≥ 600Lx
Power supply: AC220V/50Hz
Maximum power: 500VA
Workspace size (W * D * H) MM: 1360X590X540
Overall dimensions (W * D * H) MM: 1480X630X1540
- Product Details
- Product manual
Model: SW-CJ-2FD
Product Description: This product provides a dust-free and sterile local air purification working environment, widely used in research on electronic technology, aerospace, precision instruments, instruments, fine chemicals, food, etc. Adopting a fan system with adjustable air volume, the average wind speed in the working area is maintained within the rated range by adjusting the operating conditions of the fan, effectively extending the service life of the filter. This equipment is an air purification equipment that provides a local high cleanliness working environment, widely used in research and application fields such as biopharmaceuticals, biochemistry, environmental monitoring, and electronic instruments.
Product features:
● Fan system with adjustable air volume
Good low noise fan
304 stainless steel workbench
● Equipped with lighting and UV sterilization lights in the work area
● Precautions
1. This product must be reliably grounded (zero or neutral wires cannot be used as grounding wires)
2. Before use, please confirm that the voltage and frequency of the power supply match the product requirements
3. Do not insert fingers or foreign objects into the air supply or air inlet
4. It is prohibited to use alcohol lamps and other open flames in the work area
5. It is not allowed to unplug or plug in the power plug of the product without turning off the power switch during operation
6. It is not allowed to arbitrarily lengthen or shorten the product's power connection
7. High temperature and humidity are strictly prohibited in the laboratory environment
8. The workbench should not store items that are prone to dust, to ensure that the clean airflow in the work area is not disturbed
9. Equipment should be kept away from direct sunlight, external airflow interference, high-speed dust sources, seismic sources, and high-frequency electromagnetic interference sources
